dmidecode -t memory
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 3.0.1 present.
Handle 0x0020, DMI type 16, 23 bytes
Physical Memory Array
Location: System Board Or Motherboard
Use: System Memory
Error Correction Type: None
Maximum Capacity: 8 GB
Error Information Handle: No Error
Number Of Devices: 2
Handle 0x0021, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x0020
Error Information Handle: No Error
Total Width: 64 bits
Data Width: 64 bits
Size: 8192 MB
Form Factor: SODIMM
Set: None
Locator: ChannelA-DIMM0
Bank Locator: BANK 0
Type: DDR4
Type Detail: Synchronous Unbuffered (Unregistered)
Speed: 2400 MT/s
Manufacturer: Samsung
Serial Number: 38708FD5
Asset Tag:
Part Number: M471A1K43CB1-CRC
Rank: 1
Configured Memory Speed: 2400 MT/s
Minimum Voltage: 1.2 V
Maximum Voltage: 1.2 V
Configured Voltage: 1.2 V
Handle 0x0022, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x0020
Error Information Handle: No Error
Total Width: 64 bits
Data Width: 64 bits
Size: 2048 MB
Form Factor: Row Of Chips
Set: None
Locator: ChannelB-DIMM0
Bank Locator: BANK 1
Type: DDR4
Type Detail: Synchronous Unbuffered (Unregistered)
Speed: 2400 MT/s
Manufacturer: Synology
Serial Number: 00000000
Asset Tag:
Part Number:
Rank: 1
Configured Memory Speed: 2400 MT/s
Minimum Voltage: 1.2 V
Maximum Voltage: 1.2 V
Configured Voltage: 1.2 V
dmidecode -t 0
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 3.0.1 present.
Handle 0x0000, DMI type 0, 24 bytes
BIOS Information
Vendor: INSYDE Corp.
Version: M.119.00
Release Date: 06/04/2021
Address: 0xF0000
Runtime Size: 64 kB
ROM Size: 3072 kB
Characteristics:
PCI is supported
BIOS is upgradeable
BIOS shadowing is allowed
Boot from CD is supported
Selectable boot is supported
EDD is supported
8042 keyboard services are supported (int 9h)
Serial services are supported (int 14h)
Printer services are supported (int 17h)
CGA/mono video services are supported (int 10h)
ACPI is supported
USB legacy is supported
ATAPI Zip drive boot is supported
BIOS boot specification is supported
Function key-initiated network boot is supported
Targeted content distribution is supported
BIOS Revision: 5.4
Firmware Revision: 0.0
dmidecode -t 2
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 3.0.1 present.
Handle 0x0002, DMI type 2, 17 bytes
Base Board Information
Manufacturer: Synology
Product Name: DS720+
Version: 1.0
Serial Number: 123456789
Asset Tag: Type2 - Board Asset Tag
Features:
Board is a hosting board
Board is replaceable
Location In Chassis: Type2 - Board Chassis Location
Chassis Handle: 0x0003
Type: Motherboard
Contained Object Handles: 0
Früher hätte man das Gerät in den Technikladen mitgenommen und alle Speicher durchprobiert bis es passt. Wo hat Amazon seinen nächsten Laden?
gefunden.Du musst per SSH/Terminal bspw. mit Putty auf die DS, dann mit "sudo su" zum root user wechseln (dein Pw nochmals eingeben) und dann den Befehl "dmidecode" ausführen, dann werden sämtliche Hardware-Daten angezeigt, in den ersten drei Blöcken findest du die Infos bzgl BIOS und Mainboard
